120 MM Double Wall Corrugated Pipe

Get a Price/Quote

120 MM Double Wall Corrugated Pipe Specification

Coating Type
UV Stabilized

Bend Radius
Min. 14 x Outer Diameter

Flexibility
High

Tensile Strength
>19 MPa

Yield Strength
16 MPa

Sealing Type
Gasket or Rubber Ring

Diameter
120 mm

Temperature Range
-20C to +60C

Tolerance
2 mm

Connection Type
Socket / Bell End

Product Type
Double Wall Corrugated Pipe

Material
HDPE (High Density Polyethylene)

Connection
Push-fit / Coupler Joint

Shape
Round

Standard
IS 16098 Part 2

Surface Treatment
Smooth Inner, Corrugated Outer

Outer Diameter
120 mm

Section Shape
Circular

Length
6 m (Standard)

Thickness
5-7 mm

Color
Black with Yellow Inner Lining

Usage
Underground Cable Protection, Drainage, Sewerage

Rated Pressure
Non-Pressure

Application
Cabling, Drainage, Sewerage, Stormwater Management

Material Grade
PE100

Ring Stiffness
4 kN/m (SN4), 8 kN/m (SN8)

Hydraulic Capacity
High Smooth Bore

Chemical Resistance
Excellent

UV Resistance
Yes

Life Expectancy
> 50 Years

Fire Retardant
No

Abrasion Resistance
Excellent

Weight (Approx.)
1.7-2.3 kg/m

Corrugation Height
8.5 mm

Inner Diameter
103 mm

120 MM Double Wall Corrugated Pipe Trade Information

Supply Ability
5000 Per Month

Delivery Time
7 Days

Main Domestic Market
Gujarat

About 120 MM Double Wall Corrugated Pipe

Find the ideal solution for underground cable protection, drainage, and sewerage with our 120 MM Double Wall Corrugated Pipe. Buy with confidence, knowing you will receive a product crafted from superior HDPE (PE100) material, offering transcendent durability and chemical resistance. Purchase this pipe to benefit from high hydraulic capacity, excellent abrasion resistance, and outstanding UV stability. Its valuable features, including a smooth inner surface and a robust corrugated outer wall, ensure a service life of over 50 years, making every investment worthwhile for cabling, drainage, and stormwater management needs.

Key Advantages and Usage Directions for 120 MM Double Wall Corrugated Pipe

The 120 MM Double Wall Corrugated Pipe stands out with its high flexibility, superior hydraulic flow due to a smooth bore, and remarkable chemical and abrasion resistance. To use, align the push-fit or coupler joint ends for fast installation. Its competitive advantage lies in its lightweight, easy handling, and compliance with IS 16098 Part 2 standards. This pipe ensures reliable performance in underground installations for drainage and cable protection, providing longevity and minimal maintenance requirements.

Export Market, Sample Policy, and Transportation for 120 MM Double Wall Corrugated Pipe

We cater to valuable export markets across Asia, Africa, the Middle East, and Europe for the 120 MM Double Wall Corrugated Pipe. Quotations are promptly provided upon request. Sample policies are flexiblesamples are available on demand to ensure satisfaction before large orders. Goods transport is arranged from major FOB ports in India, guaranteeing safe, reliable transportation. Our superior logistics ensure quick and secure delivery, reinforcing our commitment to quality and customer service globally.

FAQs of 120 MM Double Wall Corrugated Pipe:

Q: How is the 120 MM Double Wall Corrugated Pipe installed for underground cable protection or drainage?

A: The 120 MM Double Wall Corrugated Pipe uses a push-fit or coupler joint system for quick and secure installation. Simply align and connect the socket or bell ends, ensuring the gasket or rubber ring seal is properly in place to prevent leakage.

Q: What are the primary benefits of choosing this pipe for sewerage and stormwater management?

A: This pipe offers exceptional chemical and abrasion resistance, high flexibility, UV stability, and a superior hydraulic capacity with its smooth inner bore. These features combine to deliver long life, reduced maintenance, and reliable performance in sewerage and stormwater systems.

Q: Where is the 120 MM Double Wall Corrugated Pipe commonly used?

A: It is widely used in underground cable protection, municipal and industrial drainage, sewerage systems, and stormwater management projects due to its durability and adherence to international standards.

Q: What makes this pipe superior compared to conventional piping solutions?

A: Its double wall design enhances ring stiffness (SN4 and SN8), lightweight structure aids in quick installation, and the HDPE material offers excellent resistance to chemicals, UV exposure, and abrasion, ensuring transcendent longevity and structural integrity.

Q: How should I request a quotation or sample for international orders?

A: Contact our sales team with your requirements, and a detailed quotation will be provided. Samples are available on request, and transportation can be arranged from major FOB ports in India for seamless goods delivery worldwide.
